ASIC Repair Basics: Antminer S19 Common Faults and Solutions

Table of Contents

The Antminer S19 is a cutting-edge ASIC miner designed to make Bitcoin mining more efficient and powerful. With hash rates of up to 110 TH/s and 34.5J/TH energy efficiency, this advanced three-board system offers an impressive 8.6 TH/s per chip with no compromise on performance or reliability – all protected by integrated dust, humidity & overvoltage safeguards for long-term operation in even the most rugged industrial settings like data centers and warehouses; included web management further allows users full control from afar!

Common Faults and Causes

Common faults and causes of the Antminer S19 can include hardware malfunctions, software issues, or environmental factors. Several things, such as faulty chips, poor soldering connections, or other physical damage, can cause hardware malfunctions. Software issues may arise from incorrect configuration settings or improper firmware updates. Environmental factors such as dust buildup on components and extreme temperatures can also lead to problems with the miner’s performance.

It is essential for miners to regularly inspect their rigs to detect any potential issues before they become severe enough to cause significant damage or downtime. Additionally, troubleshooting steps such as checking for short circuits before powering up the rig and inspecting all chip test points should be followed when attempting repairs on an Antminer S19.

For more complex repairs, miners can rely on the experienced team of technicians at D-Central to help diagnose and fix any issues. With our premium equipment and customer-tailored services, we are committed to helping customers get back up and running quickly with minimal disruption. From new machines to refurbished units or even replacement parts, D-Central has all your mining needs covered.

Pre-Repair Checklist & Troubleshooting Tips

Pre-repair checklist and troubleshooting tips are essential for miners looking to optimize their Antminer S19’s performance. From checking components for physical damage and dust buildup to reconfiguring settings or performing firmware updates, several steps need to be taken to diagnose any potential problems with the miner before attempting repairs. By following this pre-repair checklist and troubleshooting tips, miners can quickly identify any issues while minimizing the risk of further damages due to improper repairs.

Before attempting any repairs or maintenance on an Antminer S19, it is vital to complete a pre-repair checklist. This includes:

  1. Visually inspect all components for dust buildup and physical damage;
  2. Checking the miner’s settings and making sure they are properly configured;
  3. Ensuring that the latest firmware updates have been applied correctly;
  4. Verifying that there are no short circuits present in any of the cables or power connections used with the miner;
  5. Inspecting all printed circuit boards (PCBs) for signs of wear or defectiveness before repair attempts.

In addition to the pre-repair checklist, there are several troubleshooting tips that miners can use to help diagnose any potential problems with their Antminer S19. These include:

  1. Power cycling – This involves turning the miner off and then on again to reset any faulty settings or errors;
  2. Heat testing – To test for heat-related issues, miners should power down their rig and let it sit aside and cool before testing again;
  3. Board inspection – Carefully inspecting each board for signs of physical damage or corrosion can help pinpoint any areas prone to failure; and
  4. Firmware update – If a firmware update is needed, miners should follow all instructions and download the latest version.

By following this pre-repair checklist and troubleshooting tips, miners can reduce the risk of incurring further damages due to improper repairs or maintenance on their Antminer S19. Additionally, services provided by D-Central can help miners quickly diagnose and repair any issues they may have with their mining rigs in a safe and secure environment. With their extensive selection of hardware, tailored services for third parties, and professional team of technicians, D-Central is the go-to source for all your mining needs.

Routine Inspection Process for ASIC Repair

Maintaining and repairing ASIC miners is an essential part of maximizing profits in the cryptocurrency mining industry. To ensure that miners are running optimally, it is essential to regularly inspect them for any potential issues before they become severe enough to cause significant downtime or damage. The routine inspection process for ASIC repair involves checking for short circuits before powering up the rig, inspecting all chip test points, and monitoring temperature levels and dust buildup on components. By following this process regularly, miners can quickly identify any problems with their rigs while minimizing the risk of incurring further damages due to improper repairs.

By following the pre-repair checklist steps outlined above and taking advantage of D-Central’s top-notch support services, miners will be able to keep their rigs running optimally for more extended periods of time while minimizing downtime due to technical problems. This will help maximize profits in the cryptocurrency mining sector by allowing miners to take full advantage of their Antminer S19’s capabilities.

Testing Status of a Typical Miner

Testing the status of a typical miner is an essential part of ensuring optimal performance. It involves visually inspecting the hashboard to look for signs of PCB deformation or scorching and testing impedance levels to detect any short circuits or open circuits. The voltage domain should also be tested to ensure it is within an acceptable range. Once these tests are passed, a chip test can be done using a hashboard tester which will help determine any faulty chips that may need further repair or replacement. Additionally, signals such as CLK CO BO RST must be forward transmitted to locate abnormal fault points and ensure proper power supply sequence. Finally, after resoldering any necessary chips and performing additional tests with the hash board tester, the repaired hash board can be judged good if it passes advanced testing at least twice.

Low Hashrate on One Hashboard

When mining cryptocurrencies, a low hash rate on one of your hash boards can be incredibly frustrating. It is crucial to diagnose and fix the problem as quickly as possible to maximize profits and minimize downtime. To do this, miners must take the time to troubleshoot and identify what is causing the issue by using Putty or other remote testing software, visually inspecting for signs of PCB deformation or scorching, testing impedance levels, and checking voltage domain levels within an acceptable range. With D-Central’s professional team of technicians available for assistance, miners can ensure their rigs run optimally while minimizing downtime due to technical problems.

Following the Maintenance Flowchart

The maintenance Flowchart involves a series of steps to ensure the successful repair of a hashboard.

  1. Routine inspection: Visually inspect the hash board and test the impedance of each voltage domain
  2. Perform chip tests with a hash board tester, and locate faulty chips according to the results
  3. Check chip test points (CO/NRST/RO/XIN/BI) and voltages such as VDD0V8 and VDD1V8 for near-faulty chips
  4. Trace signal flow from No. 1 to 76 chip; abnormal fault point can be found through power supply sequence
  5. Re-solder faulty chips using flux, heat solder joints until the dissolved state is achieved
  6. Use a hashboard tester to judge repaired hash boards; two passes are required for a successful repair

We start with the routine inspection, which involves visually inspecting the hashboard for deformation, scorching, burnt marks on parts, offset or missing parts. Secondly, an impedance test is performed on each voltage domain to detect short-circuits or open-circuits and check whether the voltage of each domain is approximately 0.36V. If the routine test passes inspection, a chip test can be performed using a hash board tester to determine where repairs need to be made. Once the faulty chip is located, it needs to be re-soldered with flux and undergo heat application until all solder joints have been dissolved and collected into tinning again. After completing this process, it must be tested again with the hash board tester. If passed, then it can be set aside and allowed to cool down before undergoing a second test after a few minutes have passed once it has cooled down. If both tests are passed, the repaired hash board can be considered good and ready for use. In addition, extra attention should also be paid when testing for short-circuits to avoid chips and other materials from burning due to potential short-circuit dangers when power is turned on. These safety measures must be taken when conducting repairs to prevent any further damage from being done during maintenance procedures.

Replacing Parts and Re-Soldering Chips

Replacing parts and re-soldering chips is an essential part of maintaining a mining rig. When a hash board malfunctions, it must be tested to determine which chip or component needs to be replaced. Once identified, the faulty chip can then be removed and replaced with a new one before being soldered back into place. Re-soldering helps ensure that all connections are secure and free from short circuits, preventing further damage down the line. With D-Central’s professional team of technicians available for assistance, miners can ensure their rigs run optimally while minimizing downtime due to technical problems.

Final Testing After Repairs Are Complete

Once the repairs of a hash board have been completed, a final test must be conducted to ensure that all components are functioning correctly and there are no lingering issues. This testing can involve connecting the hash board to its mining pool and running tests to check the hash rate and other performance metrics. It is essential to not just rely on the routine inspection and chip test results, as these tests may not be comprehensive enough to detect any underlying issues. Additionally, voltage domains should also be tested on each chip before powering on the system to prevent short circuits or open circuits from occurring. Hashboard testers are explicitly designed for this purpose, as they can accurately detect faulty chips and provide detailed feedback about what needs to be fixed for a repair to be successful. Furthermore, tests can also be performed on any signals that have been reversed or forwarded to ensure they are functioning correctly. After all, tests have been completed successfully, and all faults have been resolved, one can judge the repaired hashboard as good if it passes two tests with a hashboard tester. It is essential to wait for the hash board to cool down between tests for accurate results; otherwise, there might be an increase in temperature, which could lead to false readings. Once all tests pass, miners can rest assured knowing their repairs were successful and their rig will run optimally again without compromising its performance or safety features.


Mining rigs require regular maintenance and repairs to ensure optimal performance. By leveraging the power of hashboard testers, miners can accurately identify faulty chips or components that need replacing before re-soldering them back into place with flux and heat application. After all, repairs are complete. It is essential to perform a final test on each component and any signals that have been reversed or forwarded for the system to run safely without compromising its performance. With these steps taken, miners can rest assured knowing their rig will run optimally again after passing two tests with a hash board tester. Ultimately, by following this process carefully, miners can maintain their rigs effectively while avoiding potential short-circuit dangers when powering up their systems.
