6-15p To C19 Power Cable
The 6-15p to c19 power cable is a quality power solution for mining setups.
Connect your ASIC miner to a NEMA 6-15 (240V) outlet with this heavy-duty power cable. The 6-15P plug connects to your 240V wall outlet, and the C19 connector plugs into miners and power supplies that use the larger IEC C20 inlet — including Antminer APW7, APW9, APW12, and APW17 power supplies.| Specifications | |
|---|---|
| Connector A | NEMA 6-15P (240V plug, 3-prong) |
| Connector B | IEC 60320 C19 |
| Amperage | 15A |
| Voltage | 250V |
| Wire Gauge | 14AWG, 3 conductor |
| Jacket | SJT (Heavy Duty) |
| Color | Black |
| Approvals | UL/cUL, CSA |
Common Mining Uses
- Antminer S19 / S21 series — APW12 and APW17 PSUs use C20 inlets (accepts C19 plug)
- Whatsminer M30S / M50 series — built-in PSUs with C20 inlets
- PDU connections — 6-15P plug to C19 PDU outlet in mining setups
What is the difference between C19 and C13?
C19 is the larger connector rated for up to 20A, used on high-power ASIC miners and their PSUs. C13 is the smaller connector (like a standard computer power cable) rated for up to 15A. If your miner’s PSU has a rectangular inlet about 2 inches wide, you need C19. If it looks like a standard PC power plug, you need C13.
Is 6-15P the right plug for my outlet?
NEMA 6-15 outlets are 240V receptacles with two horizontal prongs and a round ground pin. They are commonly installed for window AC units and workshops. If your outlet has one horizontal and one vertical prong (T-shaped), that is a 6-20R and you need a 6-20P plug instead.
D-Central Technologies — Bitcoin Mining Hackers since 2016. The right cable for the right setup. Every hash counts.
What is the difference between C19 and C13?
C19 is the larger connector rated for up to 20A, used on high-power ASIC miners and their PSUs. C13 is the smaller connector (like a standard computer power cable) rated for up to 15A. If your miner’s PSU has a rectangular inlet about 2 inches wide, you need C19. If it looks like a standard PC power plug, you need C13.
Is 6-15P the right plug for my outlet?
NEMA 6-15 outlets are 240V receptacles with two horizontal prongs and a round ground pin. They are commonly installed for window AC units and workshops. If your outlet has one horizontal and one vertical prong (T-shaped), that is a 6-20R and you need a 6-20P plug instead.
