The MicroBT Whatsminer M60S is MicroBT’s current-generation flagship air-cooled Bitcoin miner, delivering 186 TH/s at 18.5 J/TH. As MicroBT’s answer to Bitmain’s S21 series, the M60S represents a significant step forward from the M50 generation and positions MicroBT as a serious alternative for miners who want to diversify their hardware fleet beyond a single manufacturer.
The M60S uses MicroBT’s proprietary ASIC chip design and features the characteristic Whatsminer form factor with its single-board controller and robust build quality. For operations seeking supply chain diversification or preferring MicroBT’s management software, the M60S delivers competitive performance.
Whatsminer M60S Full Specifications
| Specification | Details |
|---|---|
| Manufacturer | MicroBT |
| Model | Whatsminer M60S |
| Algorithm | SHA-256 |
| Hashrate | 186 TH/s |
| Power Consumption | 3,441W (±5%) |
| Efficiency | 18.5 J/TH |
| Noise Level | 75 dB |
| Weight | 12.8 kg |
| Dimensions | 430 x 155 x 240 mm |
| Operating Temperature | 5-45 °C |
| Cooling | 2 x high-speed fans (air-cooled) |
| ASIC Chip | MicroBT proprietary |
| Chip Count | ~312 |
| Input Voltage | 200-277V AC (integrated PSU) |
| Network Connection | Ethernet (RJ45) |
| Release Date | 2024 |
Performance Analysis
At 18.5 J/TH, the Whatsminer M60S falls between the Antminer S21 (17.5 J/TH) and the Antminer T21 (19 J/TH). It is significantly more efficient than the entire S19 generation — outperforming the S19 XP (21.5 J/TH) by 14% and the S19k Pro (23 J/TH) by 20%.
Against Bitmain’s premium S21 variants, the M60S falls further behind: the S21 Pro at 15 J/TH and S21 XP at 13.5 J/TH are substantially more efficient. However, the M60S competes on price and offers the advantage of an integrated power supply, simplifying deployment.
A key differentiator of the Whatsminer platform is its integrated PSU — you do not need a separate power supply unit, reducing total system cost, cabling complexity, and potential failure points. This is a meaningful advantage for both farm and home deployments.
For a full ranking of miners by efficiency, see our Most Efficient Bitcoin Miners 2026 guide.
Profitability Snapshot
Estimated daily revenue and cost at current network difficulty (approximate, based on typical 2026 conditions). Actual results depend on Bitcoin price, network difficulty, and pool fees.
| Electricity Rate | Daily Power Cost | Monthly Power Cost | Viability |
|---|---|---|---|
| $0.05/kWh | $4.13 | $124 | Highly profitable — competitive with S21-class machines at cheap power |
| $0.08/kWh | $6.61 | $198 | Profitable — solid margins at average North American electricity rates |
| $0.10/kWh | $8.26 | $248 | Marginal — viable but watch difficulty trends and BTC price |
| $0.12/kWh | $9.91 | $297 | Tight — consider dual-purpose heating or power curtailment to maintain viability |
Use our Bitcoin Mining Profitability Calculator for real-time estimates with your exact electricity rate, or check our Bitcoin Mining Electricity Cost by State & Province guide to find your local rate.
Best Use Cases
Mining Farms (Fleet Diversification): Running an all-Bitmain fleet creates single-manufacturer risk — firmware vulnerabilities, supply chain issues, or control board exploits could affect your entire operation. Adding M60S units provides hardware diversity, and the integrated PSU simplifies deployment logistics.
Home Mining: The M60S’s integrated PSU means one less component to buy, cable, and potentially troubleshoot. At 3,441W and 75 dB, it requires the same 220V+ dedicated circuit and ventilation as comparable Antminers. A D-Central cooling shroud designed for Whatsminer form factors helps manage airflow and noise.
Dual-Purpose Heating: The M60S outputs approximately 11,741 BTU/h of heat. Like all full-size ASIC miners, this waste heat is pure, clean, electric resistance heating that can be ducted into living spaces. See our Bitcoin Space Heater vs Electric Heater analysis.
Regions with Voltage Variability: The M60S accepts a wide input voltage range (200-277V AC) through its integrated PSU, making it slightly more flexible for deployment in regions with variable grid voltage.
Compatible Firmware
| Firmware | Compatibility | Key Features |
|---|---|---|
| Stock (MicroBT) | Full support | Default firmware with MicroBT management tools, built-in overclocking options |
| Braiins OS+ | Not supported | Braiins OS+ currently does not support Whatsminer models |
| Vnish | Supported | Custom profiles, overclocking, immersion mode support |
| LuxOS | Not supported | LuxOS currently focuses on Antminer models |
Important note: The Whatsminer firmware ecosystem is more limited than Antminer’s. MicroBT’s stock firmware includes built-in performance tuning features (power modes, overclocking settings) that partially compensate for the smaller third-party ecosystem. Vnish offers the primary third-party option for advanced users.
For general firmware guidance, see our Mining Firmware for Beginners guide and Bitcoin Mining Software Comparison 2026.
Common Issues & Repair
Common issues with the Whatsminer M60S include:
- Hashboard failures: ASIC chip failures can reduce hashboard output. Whatsminer hashboards use a different connector and layout than Antminers, requiring Whatsminer-specific repair expertise.
- Integrated PSU issues: While eliminating the external PSU is convenient, it also means PSU failures require servicing the entire unit rather than swapping a commodity part.
- Fan errors: The M60S uses two large fans. Failures trigger protective shutdown. Whatsminer fans differ in connector type from Antminer fans.
- Temperature warnings: Ensure ambient temperatures stay within the 5-45 degrees C range. The Whatsminer form factor has different airflow characteristics than Antminers.
- Control board issues: Whatsminer control boards are manufacturer-specific. Replacement requires MicroBT-compatible parts.
D-Central offers professional Whatsminer M60S Repair services from our Canadian workshop. Our technicians are trained on both Antminer and Whatsminer platforms, with access to Whatsminer-specific diagnostic tools and parts. See our ASIC Repair Cost Estimator for pricing.
Where to Buy
Contact D-Central for Whatsminer M60S availability and pricing. We ship across Canada and internationally. Our sales team can help you evaluate whether the M60S or a comparable Antminer model best fits your operation’s needs, electricity rate, and infrastructure. We also stock Whatsminer-compatible cooling shrouds and accessories.
