Goldshell AL MAX specifications and service reference
Goldshell AL MAX official 8.3 TH/s Blake3 matrix, electrical boundary, physical fields, and firmware evidence status.
Quick answer
The Goldshell AL MAX specifications and service reference is a Blake3 miner rated about 8.3 TH/s at roughly 3,350 W.
Full Specifications
| Model | Goldshell AL MAX specifications and service reference |
|---|---|
| Manufacturer | Goldshell |
| Algorithm | Blake3 |
| Hashrate | 8.3 TH/s |
| Power Consumption | 3,350 W |
| Efficiency | 403 J/TH |
| Noise Level | 60 dB |
| Voltage Range | 180-280 V |
| Operating Temperature | 0-35 C |
| Dimensions | 264 x 200 x 290 mm |
| Weight | 13.5 kg |
| Status | Lifecycle not independently verified |
Manufacturer-supported specification
Goldshell AL MAX
Goldshell publishes one default Blake3 operating lane for AL MAX: 8.3 TH/s ±5% at 3350 W ±5%, labeled 403 J/TH. The manufacturer lists ALPH for this exact model.
Exact operating lane
| Mode | Hashrate | Power | OEM efficiency |
|---|---|---|---|
| Default | 8.3 TH/s ±5% | 3350 W ±5% | 403 J/TH |
The OEM efficiency label is preserved exactly. Nominal arithmetic is approximately 403.61 J/TH; that calculated value is not substituted for the published label. The cited table publishes no low-power row.
Electrical and environment
The manufacturer lists 180–280 V input, Ethernet networking, recommended operating temperature 0–35°C, relative humidity at or below 65%, and a 6000 rpm fan specification. Its separate Power Cable Specification
field says 16 A. That is retained only as the OEM cable label; it is not measured facility current, breaker sizing, phase, frequency, plug, conductor, or overcurrent-protection guidance.
Verify the nameplate, site voltage, cord, connector, frequency, phase, and protective devices with a qualified installer before energizing the machine.
Physical and acoustic fields
Miner dimensions are 264 × 200 × 290 mm and net weight is 13.5 kg. Package dimensions are 370 × 305 × 450 mm and packaged weight is 15 kg. The manufacturer states noise at or below 60 dB; no test geometry or acoustic method is published, so this remains an exact table label rather than a site guarantee.
Firmware boundary
The official manufacturer firmware repository was checked by exact model name. It does not currently expose an AL MAX artifact or exact-model directory. Do not select firmware from similarly named products. Use the manufacturer support center and confirm the exact model and serial number before any update.
Official firmware selector · Official AL MAX specification table · Manufacturer support
Service boundary
No chip process/count, board count, controller model, PSU architecture, tuning, residential-use score, heat-use claim, economics, profitability, firmware compatibility, or parts interchangeability is asserted.
