Bitmain Antminer D7 1286 GH/s X11 official reference
Official Antminer D7 X11 reference: 1,286 GH/s, 3,148 W and the OEM 2.4 J/G efficiency field, with exact four-fan, electrical, firmware and repair boundaries.
Quick answer
The Bitmain Antminer D7 1286 GH/s X11 official reference is a X11 miner rated about 1286 GH/s at roughly 3,148 W.
Full Specifications
| Model | Bitmain Antminer D7 1286 GH/s X11 official reference |
|---|---|
| Model Number | Antminer D7 |
| Manufacturer | Bitmain |
| Algorithm | X11 |
| Coins Mined | Dash (DASH) |
| Hashrate | 1286 GH/s |
| Power Consumption | 3,148 W |
| Efficiency | 2.45 J/GH |
| Noise Level | 70 dB |
| Chip Count | 210 |
| Cooling | Air |
| Voltage Range | 200-240 V AC; two AC power ports; frequency and current unresolved |
| Operating Temperature | 0 C to 40 C |
| Dimensions | 400 x 195.5 x 290 mm |
| Weight | 14.4 kg net |
| Interface | Ethernet |
| BTU Output | 10,741 BTU/hr |
| Equivalent Heater | Equal to a 3,148W space heater |
| Daily Power Cost | $5.29/day |
| Monthly Power Cost | $158.66/mo |
| Circuit Requirement | 200-240 V AC; two AC power ports; frequency and current unresolved - confirm phases, current, connector and protection from the nameplate and manual |
| Status | OEM support reference |
Evidence-controlled D7 reference: Antminer D7 is an X11 miner associated with DASH in Bitmain’s official algorithm map. Hashrate and efficiency remain in X11-native source units and must not be compared numerically across algorithms.
| Model | Hashrate | Power consumption | OEM efficiency field |
|---|---|---|---|
| D7 | 1,286 GH/s | 3,148 W | 2.4 J/G ±10% |
Efficiency-unit note: Bitmain prints 2.4 J/G ±10%. Direct arithmetic gives 3,148 W ÷ 1,286 GH/s = approximately 2.4479 J/GH, equivalently 2,447.9 J/TH. Those arithmetic equivalents explain the ratio but are not replacement OEM claims. Metadata and structured data must not describe 2,447.9 J/TH as Bitmain’s published efficiency.
Electrical and installation boundary
| AC input voltage | 200–240 V AC |
|---|---|
| AC power ports | 2 |
Have a qualified person verify the exact D7 and installed PSU labels, both power ports, cords, connectors, circuit capacity, protection, conductors, disconnecting means, grounding, ventilation, and applicable requirements before energizing. Exact mains frequency, maximum current, cord/connector model, PSU submodel, and power-on sequence are not asserted without exact D7 evidence.
Cooling, hardware, and physical facts
| Operating frequency | 625M, as printed by Bitmain |
|---|---|
| Fans | Four 12038 fans; 6,000 RPM front and rear; 12 V / 2.7 A; 320 CFM mid airflow |
| Hashboards / chips | 3 / 210 total |
| PCB protection temperature | 80°C |
| Operating temperature | 0–40°C |
| Humidity | 10–90% RH, non-condensing |
| Sound | 70 dB |
| Miner dimensions | 400 × 195.5 × 290 mm |
| Packaged dimensions | 570 × 316 × 430 mm |
| Net / gross weight | 14.4 kg / 16.1 kg |
Storage temperature and operating altitude are not published on the exact D7 specification and remain unresolved.
Firmware, diagnostics, and repair
- Select D7 and the exact installed revision in Bitmain’s firmware selector.
- Use Bitmain’s exact D7 support hub for setup, reset, firmware, troubleshooting, and service resources.
- Use Bitmain’s miner failure diagnostic guide.
- Organize symptoms and logs with the ASIC fault finder.
- Open the Antminer D7 repair route with exact labels, photographs, logs, symptoms, and prior firmware actions.
- Open the general ASIC repair service.
Evidence boundaries: no control-board or software architecture, silicon/process, voltage-domain behavior, PSU or parts interchangeability, tuning, economics, residential suitability, heat-use, lifecycle, or cross-model compatibility claim is asserted.
Primary sources: Bitmain’s D7 specification, algorithm map, fan table, and the exact support and diagnostic routes above. Reviewed August 28, 2026.
