Bitmain Antminer X5 RandomX official unit-conflict reference
Official Antminer X5 version 240-Z reference: RandomX/XMR and 1,350 W, with incompatible printed hashrate and efficiency units preserved and normalized fields withheld.
Quick answer
The Bitmain Antminer X5 RandomX official unit-conflict reference is a Randomx miner rated about TH/s at roughly 1,350 W.
Full Specifications
| Model | Bitmain Antminer X5 RandomX official unit-conflict reference |
|---|---|
| Model Number | Antminer X5 version 240-Z |
| Manufacturer | Bitmain |
| Algorithm | Randomx |
| Coins Mined | Monero (XMR) |
| Power Consumption | 1,350 W |
| Voltage Range | 200-240 V AC; 47-63 Hz; two 10 A input wires; 20 A maximum |
| Operating Temperature | 0 C to 40 C |
| Dimensions | 480 x 195.5 x 290 mm |
| Weight | 14.875 kg net |
| Interface | RJ45 Ethernet 10/100M |
| Status | OEM source-conflict reference |
Evidence-controlled X5 reference: Bitmain identifies Antminer X5, version 240-Z, with RandomX/XMR. Its exact specification contains incompatible hashrate and efficiency unit labels, so normalized hashrate and efficiency are withheld from metadata and structured data.
| Exact OEM field | Value as printed |
|---|---|
| Hashrate, TH/s | 212 ±3% |
| Wall power at 25°C | 1,350 W ±10% |
| Wall efficiency at 25°C, J/Ksol | 6.37 ±10% |
Official-source unit conflict: the printed 212 TH/s and 6.37 J/Ksol labels cannot both pair dimensionally with 1,350 W. If, and only if, 212 is interpreted as KH/s, the conditional arithmetic is 1,350 W ÷ 212 KH/s ≈ 6.37 J/KH. That calculation is not a correction attributed to Bitmain. Do not silently publish 212 KH/s or 6.37 J/KH as OEM fields, and do not compare these numerics across algorithms.
Exact electrical and installation boundary
X5 requires 200–240 V AC, 47–63 Hz, and 20 A through two AC input wires rated 10 A each. Wrong input voltage can damage the server. A qualified person must verify both inputs, exact labels, cords/connectors, circuit capacity, protection, conductors, disconnecting means, grounding, ventilation, and applicable requirements. No simultaneous-switching sequence is asserted without an exact X5 manual.
| Network | RJ45 Ethernet 10/100M |
|---|---|
| Miner dimensions | 480 × 195.5 × 290 mm, including PSU |
| Packaged dimensions | 597 × 317 × 427 mm |
| Net / gross weight | 14.875 kg including PSU / 16.92 kg |
| Operating / storage temperature | 0–40°C / -20–70°C |
| Operating humidity | 10–90% RH, non-condensing |
| Operating altitude | Up to 2,000 m |
The 20 A maximum condition is 40°C and 0 m altitude. From 900 m to 2,000 m, reduce the highest operating temperature by 1°C per 300 m. Sound, fans, chip/count, boards, cord/connector model, and PSU submodel are unresolved. The specification’s Secure Boot note expressly names the S19 series; it is not used as evidence of X5 behavior.
Firmware, diagnostics, and repair
- Select X5 and verify the exact installed revision in Bitmain’s firmware selector.
- Read Bitmain’s exact X5 specification.
- Use Bitmain’s generic diagnostic guide.
- Organize symptoms and logs.
- Request repair diagnosis with exact labels, photographs, logs, and prior firmware actions.
- Open the X5/X9 evidence router.
No architecture, tuning, economics, home, heat-use, compatibility, interchangeability, or X9 inheritance claim is asserted. Reviewed August 28, 2026.
