ElphaPex DG1+ revision evidence status
Conflicting FP-102 and FP-103 manufacturer manual lanes retained separately; generic specifications withheld pending exact revision binding.
Full Specifications
| Model | ElphaPex DG1+ revision evidence status |
|---|---|
| Manufacturer | Elphapex |
| Status | Revision identity unresolved |
Revision identity unresolved
ElphaPex DG1+ revision evidence status
The DG1+ name appears on two materially different manufacturer manuals. This generic record is not bound to either hardware revision, so it does not publish a comparison tuple.
Conflicting manufacturer revision lanes
| Manual lane | PSU identity | Performance table | Input table |
|---|---|---|---|
| V1.0.1, October 2024 | FP-102 | 14,400 MH/s ±3%; 3,950 W ±10%; 0.27 J/MH ±10% | 200–240 V, 47–63 Hz; 32 A; two cables typically 16 A each |
| V1.0.2, January 2025 | FP-103 | 14,000 MH/s ±3%; 3,920 W ±10%; 0.28 J/MH ±10% | 200–240 V, 47–63 Hz; two 10 A inputs |
These rows are revision evidence, not interchangeable operating modes. The manuals say actual equipment may vary. A full nameplate, PSU label, controller identity, installed firmware and manual revision are required before selecting a lane.
Electrical and firmware boundary
Do not design a circuit or select firmware from the shared DG1+ name. FP-102 and FP-103 input requirements differ, and a firmware example from one manual does not authorize cross-flashing the other revision. Photograph both power inlets and every label before service.
Withheld fields
Generic hashrate, power, efficiency, algorithm, coin, economics, acoustic, heat, home-use and compatibility fields are withheld. This page remains an identity and revision router until exact hardware evidence binds the record to one manual.
