ICERIVER KAS KS5M specifications and service reference
ICERIVER KS5M official 15 TH/s KAS matrix, electrical boundary, physical fields, and service routing.
Quick answer
The ICERIVER KAS KS5M specifications and service reference is a KHeavyHash miner rated about 15 TH/s at roughly 3,400 W.
Full Specifications
| Model | ICERIVER KAS KS5M specifications and service reference |
|---|---|
| Manufacturer | IceRiver |
| Algorithm | KHeavyHash |
| Hashrate | 15 TH/s |
| Power Consumption | 3,400 W |
| Efficiency | 226.6667 J/TH |
| Voltage Range | 200-250 V AC |
| Operating Temperature | 0-35 C |
| Dimensions | 430 x 195 x 290 mm |
| Weight | 15.5 kg |
| Status | Lifecycle not independently verified |
Manufacturer-supported specification
ICERIVER KAS KS5M
ICERIVER publishes KS5M as a KAS miner rated 15 TH/s ±10% at 3400 W ±10%.
Exact operating lane
| Workload | Hashrate | Wall power |
|---|---|---|
| KAS | 15 TH/s ±10% | 3400 W ±10% |
The cited product row does not publish efficiency. Nominal arithmetic is approximately 226.67 J/TH; this is derived-only, not an OEM efficiency label.
Electrical and environment
The product page lists 200–250 V AC input, Ethernet, and 0–35°C operating temperature. The power cable is not included. Current, frequency, phase, plug, connector, conductor, breaker, and protection requirements are not established here. A qualified installer must use the exact nameplate and local code.
Physical fields
Machine dimensions are 430 × 195 × 290 mm and net weight is 15.5 kg. Packaged dimensions are 560 × 314 × 382 mm and gross weight is 16.8 kg. Noise, humidity, fan count, chip count, board count, controller, and internal PSU architecture are withheld.
Firmware and service boundary
The official tutorial page is the current manuals and firmware selector. Select KS5M exactly; do not import a KS5L, KS3M, or another adjacent artifact. No exact firmware filename is claimed by this page.
Official manuals and firmware selector · Official KS5M product page · ASIC repair · Fault finder
No acoustic, architecture, tuning, residential-use, heat-use, profitability, economics, or interchangeability claim is made.
