Goldshell KD LITE operating modes and service reference
Goldshell KD LITE KDA reference with exact Default and Low power modes from firmware 2.2.9 and exact-model firmware safety boundaries.
Full Specifications
| Model | Goldshell KD LITE operating modes and service reference |
|---|---|
| Model Number | KD LITE |
| Manufacturer | Goldshell |
| Status | OEM KDA operating-mode reference |
Manufacturer-supported operating-mode reference
Goldshell KD LITE
Goldshell identifies KD LITE as a KDA miner. This reference preserves the two manufacturer-published modes without importing an unsupported exact algorithm spelling.
Supported firmware 2.2.9+ modes
Each hashrate, power and OEM ratio is paired within its own operating-mode row.
| Mode | Hashrate | Power | OEM ratio | Firmware |
|---|---|---|---|---|
| Default | 16.2 TH/s | 1,330 W | 82 W/T | 2.2.9+ |
| Low power | 12.2 TH/s | 900 W | 74 W/T | 2.2.9+ |
Arithmetic note: dividing watts by TH/s gives approximately 82.0988 J/TH for Default and 73.7705 J/TH for Low power. These are transparent calculations, not replacement manufacturer specifications; Goldshell’s rounded W/T labels remain authoritative as source labels.
Exact-model firmware boundary
The official repository directory is KDA-Miner/Goldshell-KDLITE/. Its exact artifacts are firmware-Goldshell-KDLITE-2.2.7.cpb, firmware-Goldshell-KDLITE-2.2.8.cpb, firmware-Goldshell-KDLITE-2.2.9.cpb, firmware-Goldshell-KDLITE-2.2.10.cpb, and firmware-Goldshell-KDLITE-2.2.11.cpb. The two operating modes above are supported from 2.2.9 onward; an older artifact’s presence does not establish mode support.
Goldshell advises that an upgrade is unnecessary when the miner operates normally. Once an upgrade begins, do not turn off power and do not operate the miner. Confirm the exact KDLITE identity and artifact before updating.
Evidence and installation boundary
KDA is the supported workload identity in the cited evidence. This page does not assert a more specific algorithm label.
The mode wattages are not facility electrical specifications. Voltage, frequency, phase, current, connector, cord, branch protection, PSU topology, dimensions, weight, noise, fans, environment, chips, boards, controller and parts compatibility remain unresolved. Verify the exact unit nameplate and exact-model documentation before installation or service.
Diagnosis and service
Record the exact model, active firmware, selected mode, symptoms and logs before changing configuration.
Fields intentionally withheld
No physical, acoustic, environmental, component, parts, commercial, residential-use, heat-reuse, economics, tuning or interchangeability claim is made.
