Goldshell X6S official modes and specifications
1787 MH/s nominal, 2195 W, 1.23 J/MH native OEM efficiency, complete mode matrix and exact 220 V evidence boundary.
Quick answer
The Goldshell X6S official modes and specifications is a Scrypt miner rated about 1787 MH/s at roughly 2,195 W.
Full Specifications
| Model | Goldshell X6S official modes and specifications |
|---|---|
| Model Number | X6S |
| Manufacturer | Goldshell |
| Algorithm | Scrypt |
| Hashrate | 1787 MH/s |
| Power Consumption | 2,195 W |
| Efficiency | 1.23 J/MH |
| Noise Level | 80 dB |
| Voltage Range | 220 V OEM input; exact single value, no range stated |
| Operating Temperature | 0-35 C |
| Dimensions | 240 x 125 x 280 mm |
| Weight | 5 kg miner |
| Status | Lifecycle not independently verified |
Goldshell X6S official modes and installation boundary
The official previous-miners specification identifies X6S as a Scrypt/LTC miner with three documented modes. Values are normalized to native MH/s and J/MH units.
Official operating modes
| Mode | Hashrate | Power | OEM efficiency |
|---|---|---|---|
| Hashrate | 1787 MH/s | 2195 W | 1.23 J/MH |
| Balance | 1616 MH/s | 1774 W | 1.1 J/MH |
| Low-Power | 1410 MH/s | 1367 W | 0.97 J/MH |
The source publishes no tolerance percentages; none are invented here.
Physical and operating facts
Miner dimensions are 240 × 125 × 280 mm and miner weight is 5 kg. The separately listed power unit measures 300 × 120 × 46 mm and weighs 1.5 kg. Connection is Ethernet, temperature is 0–35°C, relative humidity is 95% or less, and the published noise ceiling is 80 dB or less.
Electrical and firmware boundary
The OEM image states only Input Voltage: 220 V. It does not state a range, phase, frequency, current, connector, cable rating, circuit, or PSU model. Verify both unit nameplates and all facility requirements under local code. The exact official X6S firmware artifact is version 2.0.15; do not cross-flash X5 or X5S firmware.
Official previous-miners specification · Official firmware catalog
The exact OEM table identifies LTC. DOGE, home suitability, heat reuse, profitability, release, MSRP, facility circuit, and parts fitment are not asserted.
