Canaan AvalonMiner A1346 exact-bin OEM reference
Official AvalonMiner A1346 reference covering verified 107–123 TH/s listings with bin-specific power, voltage, tolerance and temperature boundaries.
Quick answer
The Canaan AvalonMiner A1346 exact-bin OEM reference is a Bitcoin miner rated about 107-123 TH/s at roughly 3,300 W (about 29 J/TH).
Full Specifications
| Model | Canaan AvalonMiner A1346 exact-bin OEM reference |
|---|---|
| Model Number | AvalonMiner A1346 |
| Manufacturer | Canaan |
| Algorithm | SHA-256 |
| Hashrate | 107-123 TH/s |
| Power Consumption | 3,300-3,570 W |
| Cooling | Air |
| Voltage Range | Exact-bin dependent: 185-285 V or 200-300 V AC |
| Operating Temperature | Exact-bin dependent: -5 C to 35 C or 0 C to 40 C |
| Dimensions | 271 x 192 x 292 mm |
| Weight | 12.8-13 kg net by exact listing |
| Interface | RJ45 Ethernet |
| Status | OEM support reference |
Official multi-bin reference: Canaan publishes several air-cooled AvalonMiner A1346 bins. The exact performance, voltage, tolerance, and temperature lane must be selected from the nameplate; the family name alone is insufficient.
| OEM bin/listing | Hashrate | Wall power | Efficiency at 25°C | Input voltage | Operating temperature |
|---|---|---|---|---|---|
| A1346-107T | 107 TH/s, ±5% | 3,310 W, ±10% | 30.9 J/TH, ±5% | 200–300 V AC | -5–35°C |
| A1346-110T, 3,300 W listing | 110 TH/s, ±3% | 3,300 W, ±5% | 30 J/TH, -5% to +8% | 185–285 V AC | -5–35°C |
| A1346-110T, 3,310 W listing | 110 TH/s, ±5% | 3,310 W, ±10% | 30 J/TH, ±5% | 200–300 V AC | 0–40°C |
| A1346-113T | 113 TH/s, ±5% | 3,310 W, ±10% | 29.3 J/TH, ±5% | 200–300 V AC | 0–40°C |
| A1346-120T | 120 TH/s, ±5% | 3,570 W, ±10% | 29.7 J/TH, ±5% | 200–300 V AC | -5–35°C |
| A1346-123T | 123 TH/s, ±5% | 3,570 W, ±10% | 29 J/TH, ±5% | 185–285 V AC | -5–35°C |
The cited listings use two 12050 fans and 271 × 192 × 292 mm net dimensions. Published net weight is approximately 12.8–13 kg by listing. Canaan’s own 126T page contains conflicting headline/body power values, so that lane is intentionally not normalized here pending an exact nameplate or corrected manufacturer record.
Electrical and identity gate
There is no safe family-wide voltage shortcut: Canaan’s exact A1346 listings span different 185–285 V and 200–300 V lanes. Match the complete suffix and nameplate, then design the circuit for that exact unit with qualified local guidance. This is not a branch-circuit or connector-sizing instruction.
Firmware, management, and recovery
Choose the exact A1346 resource in Canaan’s download picker and use its matching FMS, Avalonbuddy, or AvalonUpgradeTool instructions. A shared A-series interface does not establish cross-model or cross-revision firmware compatibility.
- Record the complete suffix and installed version before downloading.
- Use Canaan’s exact-model download route.
- For physical, electrical, thermal, hashboard, or no-boot faults, request A1346 diagnosis.
Known boundaries
No ASIC model/count, universal controller, tuning envelope, profitability, home-suitability, MSRP, or current lifecycle status is asserted. A1346 and A1366 remain separate identities.
Primary sources: Canaan’s official A1346 listings for 107T, 110T/3,300 W, 110T/3,310 W, 113T, 120T, and the official 123T record; Canaan download guidance; and Canaan firmware-upgrade guidance. Reviewed August 27, 2026.
