Canaan AvalonMiner A1166 Pro four-bin OEM reference
Official AvalonMiner A1166 Pro reference covering exact 72, 75, 78 and 81 TH/s bins with model-specific electrical, thermal, physical and firmware boundaries.
Quick answer
The Canaan AvalonMiner A1166 Pro four-bin OEM reference is a Bitcoin miner rated about 72-81 TH/s at roughly 3,400 W (about 42 J/TH).
Full Specifications
| Model | Canaan AvalonMiner A1166 Pro four-bin OEM reference |
|---|---|
| Model Number | AvalonMiner A1166 Pro |
| Manufacturer | Canaan |
| Algorithm | SHA-256 |
| Hashrate | 72-81 TH/s |
| Power Consumption | 3,400 W |
| Noise Level | 75 dB |
| Cooling | Air |
| Voltage Range | 185-285 V AC |
| Operating Temperature | -5 C to 35 C |
| Dimensions | 331 x 195 x 292 mm |
| Weight | 12.8 kg net |
| Status | OEM support reference |
Official multi-bin reference: Canaan publishes the air-cooled AvalonMiner A1166 Pro in the exact 72T, 75T, 78T, and 81T lanes below.
| OEM bin | Hashrate | Wall power | Efficiency | Input voltage |
|---|---|---|---|---|
| A1166 Pro-72T | 72 TH/s, ±3% | 3,400 W, ±5% | 47 J/TH, -5%/+8% at 25°C | 185–285 V AC |
| A1166 Pro-75T | 75 TH/s, ±3% | 3,400 W, ±5% | 45 J/TH, -5%/+8% at 25°C | 185–285 V AC |
| A1166 Pro-78T | 78 TH/s, ±3% | 3,400 W, ±5% | 44 J/TH, -5%/+8% at 25°C | 185–285 V AC |
| A1166 Pro-81T | 81 TH/s, ±3% | 3,400 W, ±5% | 42 J/TH, -5%/+8% at 25°C | 185–285 V AC |
Each exact listing specifies four 12038 fans, an operating range of -5–35°C, a maximum sound level of 75 dB, net dimensions of 331 × 195 × 292 mm, and a net weight of 12.8 kg. Packaged dimensions are 420 × 290 × 395 mm and gross weight is 14.1 kg. The listed accessory is a power supply without a power cord.
Electrical and cooling boundary
This is high-power equipment requiring a qualified installation. Verify the complete model/bin and both miner and PSU nameplates before selecting the circuit, protection, conductors, connector, cord, or ventilation. The 185–285 V AC miner range does not make different plugs, circuits, PSU revisions, or A11-series parts interchangeable.
Firmware and repair
Use only a firmware package selected for the exact A1166 Pro model and hardware revision. Similar model names and shared update utilities do not establish firmware, controller, hashboard, fan, or PSU compatibility.
- Record the exact bin, serial label, hardware revision, and installed version.
- Select A1166 Pro through Canaan’s exact-model picker.
- Use Canaan’s download guidance and FMS, AvalonBuddy, or upgrade-tool guidance only where the package explicitly supports the unit.
- For hardware faults, request A1166 Pro diagnosis.
Known boundaries: no ASIC model/count, universal controller, cross-model parts compatibility, tuning, economics, home-suitability, price, or lifecycle status is asserted.
Primary sources: Canaan’s official 72T listing, 75T listing, 78T listing, 81T listing, download guidance, and upgrade guidance. Reviewed August 27, 2026.
