MicroBT WhatsMiner M60S++

The current manufacturer product sheet defines the air-cooled WhatsMiner M60S++ family at 200-226 TH/s +/-5%, 15.5 J/T +/-5% at 25 C, and 3,230-3,570 W wall power +/-10%. These documented family ranges replace the prior mixed single-point record.

The sheet lists a 430 x 155 x 226 mm enclosure, 11.5 kg net weight, AC 220-240 V input, an IEC C19 power connection rated at 16 A or higher, 350 CFM airflow, Ethernet networking, and a -5 C to 35 C operating-temperature range.

Use the exact unit nameplate and local electrical code to size conductors, receptacles, protection, airflow, and heat rejection. The reviewed sheet does not publish noise, an ASIC part number, chip count, control-board platform, firmware branch, release date, or retail availability, so those fields remain unassigned.

Firmware and recovery

This model and cooling class do not identify its firmware or recovery media. Before any update or recovery, record the reported platform, complete miner type, installed version, cooling class, and current symptom. If any record conflicts or is unavailable, do not select a package. Do not infer an H616 recovery route from the M60S++ name.

• Confirm this miner’s platform before firmware or recovery.
• Only after the identifier returns a resolved, non-conflicting record, review official firmware and recovery scope.
• For an unknown or conflicting platform, no boot, or an electrical, thermal, cooling, or repeated-protection symptom, request WhatsMiner diagnosis.

Primary source: manufacturer M60S++ product manual, listed in the official product-manual catalog. Manual dated December 2024; current catalog record reviewed August 27, 2026.
