Bitmain Antminer S17e multi-bin reference
Official Antminer S17e reference covering 56, 60 and 64 TH/s lanes at 45 J/TH, with exact power, physical and operating limits.
Quick answer
The Bitmain Antminer S17e multi-bin reference is a Bitcoin miner rated about 56-64 TH/s at roughly 2,520 W (about 45 J/TH).
Full Specifications
| Model | Bitmain Antminer S17e multi-bin reference |
|---|---|
| Model Number | Antminer S17e |
| Manufacturer | Bitmain |
| Algorithm | SHA-256 |
| Hashrate | 56-64 TH/s |
| Power Consumption | 2,520-2,880 W |
| Noise Level | 82 dB |
| Chip Count | 405 |
| Cooling | Air |
| Voltage Range | 200-240 V AC |
| Operating Temperature | 5 C to 35 C recommended; 0 C to 40 C maximum |
| Dimensions | 340 x 178 x 304.3 mm |
| Weight | 11.3 kg net |
| Interface | RJ45 Ethernet 10/100M |
| Status | Historical OEM support reference |
Official three-bin reference: Bitmain documents the Antminer S17e in 56, 60, and 64 TH/s factory lanes. Their reference wall-power figures are 2,520, 2,700, and 2,880 W. Each lane is rated at 45 J/TH at 25 C.
| Factory lane | Reference wall power | Efficiency at 25 C |
|---|---|---|
| 56 TH/s | 2,520 W | 45 J/TH |
| 60 TH/s | 2,700 W | 45 J/TH |
| 64 TH/s | 2,880 W | 45 J/TH |
The official detailed tables report maximum hashrates of 59.95, 63.95, and 67.95 TH/s. Maximum wall power depends on lane and test condition and reaches 3,147, 3,404, and 3,739 W respectively. These values are OEM test limits, not aftermarket tuning recommendations.
Electrical, physical, and environmental limits
- AC input: 200-240 V, 47-63 Hz.
- Hardware: three hashboards and 405 chips in total.
- Network: RJ45 Ethernet 10/100M.
- Size and weight: 340 x 178 x 304.3 mm and 11.3 kg, including the PSU.
- Noise: 82 dBA under the manufacturer’s stated test condition.
- Environment: 5-35 C recommended operation, 0-40 C maximum operating range, 10-90% RH non-condensing, and -20 to 70 C storage.
Electrical boundary: The specified input range begins at 200 V. Do not connect the stock machine to 120 V or infer compatibility from an underclocked power target. Installation and circuit sizing must follow the PSU nameplate and applicable electrical code.
Why this page keeps the 64T URL
The current URL identifies the 64 TH/s lane, but this reference covers the complete official S17e matrix. The 56T and 60T values belong to the same named model and are presented here so owners can identify units without creating competing pages for every bin.
Firmware and repair boundary
A model name and hashrate do not prove which controller, recovery medium, firmware branch, or hashboard revision is installed. Used units may also have replacement assemblies. Inspect the actual hardware before choosing a file or donor part.
- Identify the exact control board before firmware or recovery work.
- Match manufacturer firmware to both the exact model and installed board.
- For boot failure, missing hashboards, incomplete ASIC detection, thermal faults, or unstable power, request an S17e diagnosis.
Primary source: Bitmain S17e Specifications. Reviewed August 27, 2026.
