Every Antminer talks to you through two board-mounted LEDs — a red fault light and a green normal light — plus the link/activity pair on the RJ45 network jack. Learn to read them and you can triage most field problems in seconds, before you open a browser. This guide decodes every LED state across the 15, 17, 19, 21 and later Antminer series — what each pattern means and the next diagnostic step for each fault.
The Two Status LEDs: Where They Are and What They Do
On air-cooled Antminers the two status LEDs sit on the control board, visible near the network port. The green LED is the “normal” (running) indicator; the red LED is the “fault” indicator. They are driven by firmware, so their pattern reflects what the software thinks is happening — which is why a misleading LED almost always points at a firmware, pool, or network condition rather than a dead component.
Hydro and immersion units differ. Fanless liquid-cooled models show the same control-board LEDs, but there is no fan-fault branch to chase — a “Fault 1” on an immersion rig means temperature or network, never a seized fan. Treat the pump and coolant flow as the equivalent of the fan on an air unit.
Normal Boot Sequence (17-series example)
Watching the boot is the fastest health check — a healthy Antminer walks through three stages:
- Power-on / initialization — both LEDs light solid together while the control board boots and enumerates the hashboards.
- Pool connect — the green LED goes out and the red LED flashes as the miner negotiates with the configured pool.
- Hashing — the pool accepts, the red LED goes out, and the green LED flashes. Hashrate is reporting. This is the steady-state “all good” pattern.
If the LEDs stall at stage 1 or 2 for more than a few minutes, use the fault table below.
Fault-Light Reference (operating state)
During operation the red (fault) and green (normal) LEDs encode the miner’s condition. Read them together:
| Red / Fault | Green / Normal | Meaning |
|---|---|---|
| Off | Flashing | Normal — hashing and reporting |
| Flashing | Off | Fault 1 |
| Solid on | Off | Fault 2 |
| Off | Solid on | Fault 3 |
| Off | Flashing | Fault 4 |
| Flashing | Flashing | Fault 5 |
“Normal” and “Fault 4” share the same pattern (red off, green flashing) — under Fault 4 the miner runs but under-performs, so always cross-check the LED against actual hashrate.
Fault 1 — miner stopped hashing
The most common catch-all fault. Work the three usual causes in order:
- Temperature protection. Over- or under-temp halts hashing. Check inlet/outlet temps, confirm ambient isn’t above the model’s rated intake, and verify airflow is unobstructed (or, on hydro/immersion, that the pump and coolant flow are live).
- Network. A miner that idles because it lost its pool often surfaces here — confirm it still has an IP and can reach the pool. (Firmware idles on pool loss; it does not run at full power into a dead connection.)
- Fan. A dead or stalled fan trips fan-fault protection. Air units report per-fan RPM — any fan reading 0 RPM is the culprit. Does not apply to fanless liquid units.
Fault 2 — pool / configuration failure
The miner booted but cannot mine:
- Pool config. Verify the stratum URL, port, and worker name are correct and the pool is up. A typo in the URL or a stale port is the top cause.
- Firmware. If the config is clean, reflash the control board with the manufacturer’s official signed image for that exact model. Never flash an image built for a different model or an unsigned build.
Fault 3 — network abnormal
- High latency / packet loss between miner and pool. Ping the pool from a machine on the same subnet.
- IP conflict or bad addressing. Two devices on one IP, or a DHCP collision, will strand the miner. Assign a static lease, or use the manufacturer’s IP-reporter (the miner answers a broadcast to announce its address) to confirm the IP it holds.
Fault 4 — control board suspect
Running but degraded. First try an SD-card recovery flash with the correct signed image to rule out corrupted firmware. If the board still misbehaves after a clean reflash, it is a hardware fault — replace the control board.
Fault 5 — low hashrate
Both LEDs flashing signals output has fallen below expectation. Common causes: network latency throttling accepted shares, a de-rated hashboard, or a chip fault on one domain dragging the board down. Check the dashboard for a hashboard reporting fewer than its full chip count, then work per-board — the S9 uses per-board power connectors, while S17/S19/S21 hashboards feed from a bolted bus-bar, so a loose seat presents differently by generation.
Locate / Blink: Finding One Miner in a Rack
To identify one unit among dozens, the firmware can strobe both LEDs on demand.
- 15 / 17 series: log in, open System → Locate, and click Start Blink — both LEDs flash together for 300 seconds or until you press Stop Blink.
- 19 series and later: log in and toggle the Locate Miner control (top-left; green when active) to flash both LEDs; toggle it grey to stop.
The Network-Port LEDs
The RJ45 jack carries its own pair: one for link (a connection to the switch) and one for activity (data passing). Colour assignment varies by model, but the states are consistent:
- Normal: the link LED is steady and the activity LED flashes with traffic.
- Both dark: no link. Re-seat the cable at both ends and swap in a known-good one; confirm the switch port is powered and up (try another port); if a good cable into a live port still yields no link, the control board’s PHY may be damaged and the board needs repair or replacement.
Common Mistakes and When to Escalate
- Trusting the LED over the dashboard. Fault 4 and Normal share a pattern — always confirm against real hashrate.
- Flashing the wrong firmware. Only ever use the official signed image for the exact model; a mismatched or unsigned build can brick the control board.
- Chasing a fan fault on a fanless unit. Hydro and immersion miners have no fans; their thermal fault is a pump/flow problem.
If a clean reflash with the correct signed image will not clear a Fault 2/4, or the network LEDs stay dark through a known-good cable and port, you are into control-board or PHY-level hardware — bench work. A persistent Fault 5 with a hashboard short on its chip count is a board-repair job, not a config fix.
